Size and shape of the pterygopalatine fossa of the skull of a child aged 3–5 years based on the analysis of computed tomography scans

Cover Page


Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

BACKGROUND: Endoscopic microsurgical techniques are used for sparing operations to remove foreign bodies of the pterygopalatine fossa, as well as neoplasms invading into it or growing out of it. These surgeries are performed not only in adults, but also in children as young as one month. For these surgeries, understanding the detailed structure and morphometric characteristics of the pterygopalatine fossa is crucial. However, detailed descriptions specific to children are lacking in the literature.

AIM: This study aimed to examine the size and shape of the pterygopalatine fossa and the relative location of nerve foramina in children aged 3 to 5 years (the period of primary dentition) using computed tomography data.

MATERIALS AND METHODS: To study the size and shape of pterygopalatine fossa, we analyzed anonymous archival frontal and axial computed tomograms of 12 children (24 pterygopalatine fossae) aged 3 to 5 years, obtained for examination of the underlying disease (brain pathology). All computed tomography scans were obtained using a helical computed tomograph (Somatom Sensation 64; Siemens, Germany) with an effective current of 63, 120 kV, a slice thickness of 0.5 mm, a reconstruction step of 0.7 mm, a collimation of 12×0.6 mm, Kernel U 70, a window width of 450 HU and a window center of 50 HU in University Clinic of Russian University of Medicine. The measurements were performed in the Cdviewer software after the preliminary measurements had determined sufficiently constant points on the contours of the pterygopalatine fossa of scans. On axial sections passing through the pterygoid canal, where the measurements had the greatest values, the following were studied: the largest width of the pterygoid canal (the distance between the anterior opening of the pterygoid canal and the orbital process of the palatine bone), the width of the medial wall and separately the width of the sphenopalatine foramen and the sphenoidal process of palate bone, the angle of deviation the medial wall from the sagittal plane, the width of the anterior wall (the distance between the most posteriorly protruding point of the anterior wall of the pterygopalatine fossa to the orbital process of the palatine bone), the greatest depth of the pterygopalatine fossa (posterior wall width) and the width of the pterygomaxillary fissure. The distance from the level of the orifice of the greater palatine canal to the anterior opening of the pterygoid canal and to the round foramen were measured on the frontal sections. According to axial tomograms, the spatial ratios between the orifice of the greater palatine canal and the round foramen and the anterior opening of the pterygoid canal, between these openings and the sphenopalatine foramen, between the round foramen and the anterior opening of the pterygoid canal were assessed.

RESULTS: The study found that the shape of the pterygopalatine fossa differs from the pyramid-like structure, featuring four distinct parts: the main one adjacent to the sphenopalatine foramen, and funnel-shaped constrictions at the vestibule of the pterygoid canal, greater palatine canal, and pterygomaxillary fissure. The data indicated minor individual differences in the size of the pterygopalatine fossa and the uniformity of its shape in children aged 3 to 5 years. The spatial relationships of the orifice of the greater palatine canal, the anterior opening of the pterygoid canal, the round foramen, and the sphenopalatine foramen openings determining the position of the nerves in the pterygopalatine fossa were clarified.

CONCLUSIONS: Pterygopalatine fossa in children aged 3 to 5 years (period of formed primary dentition) is characterized by a complex cavity structure, suggesting a different position of the pterygopalatine ganglion in it than is commonly believed. This circumstance, as well as for the first time the sizes of the pterygopalatine fossa determined by us, should be considered when developing surgical access to the pterygopalatine fossa and the pterygopalatine ganglion.

Full Text

Restricted Access

About the authors

Aleksandr S. Prokofiev

Russian University of Medicine

Email: prokofev_aleksandr83@mail.ru
ORCID iD: 0009-0008-9620-7810
SPIN-code: 2756-9756
Russian Federation, 23 bldg. 1 Boris Zhigulenkov street, 105275 Moscow

Ekaterina A. Makeeva

Russian University of Medicine

Email: makeevi@inbox.ru
ORCID iD: 0009-0005-1689-8518
SPIN-code: 9106-6445

MD, Cand. Sci. (Medicine), Assistant Professor

Russian Federation, 23 bldg. 1 Boris Zhigulenkov street, 105275 Moscow

Eugenia О. Mitrokhina

Russian University of Medicine

Email: Jony.Mitrokhina@yandex.ru
ORCID iD: 0009-0003-9697-3383
Russian Federation, 23 bldg. 1 Boris Zhigulenkov street, 105275 Moscow

Aleksandr V. Chukbar

Russian University of Medicine

Author for correspondence.
Email: achukbar@yandex.ru
ORCID iD: 0009-0002-3243-878X
SPIN-code: 8463-2948

MD, Dr. Sci. (Medicine), Professor

Russian Federation, 23 bldg. 1 Boris Zhigulenkov street, 105275 Moscow

References

  1. Austell PJ, Levinson JS, Plitt MA, et al. Endometrial sarcoma metastasis to the pterygopalatine fossa: a case report and review of the literature. Ear Nose Throat J. 2024;103(3):148–150. doi: 10.1177/0145561320983943
  2. Chang KV, Lin JA, Tseng TJ, et al. Ultrasound-guided transoral pterygopalatine fossa block: cadaveric elaboration of a novel technique. Korean J Pain. 2024;37(4):381–384. doi: 10.3344/kjp.24198
  3. Marston AP, Merritt G, Morris JM, Cofer SA. Impact of age on the anatomy of the pediatric pterygopalatine fossa and its relationship to the suprazygomatic maxillary nerve block. Int J Pediatr Otorhinolaryngol. 2018;105:85–89. doi: 10.1016/j.ijporl.2017.12.012
  4. Vuksanovic-Bozaric A, Vukcevic B, Abramovic M, et al. The pterygopalatine fossa: morphometric CT study with clinical implications. Surg Radiol Anat. 2019;41(2):161–168. doi: 10.1007/s00276-018-2136-8
  5. Echaniz G, Chan V, Maynes JT, et al. Ultrasound-guided maxillary nerve block: an anatomical study using the suprazygomatic approach. Can J Anaesth. 2020;67(2):186–193. (In French.) doi: 10.1007/s12630-019-01481-x
  6. Liu MC, Yin XR, Zhang YS, et al. Computed tomography research: relative anatomy of caldwell-luc approach in pterygopalatine fossa surgery. J Craniofac Surg. 2017;28(6):1537–1540. doi: 10.1097/SCS.0000000000003898
  7. Oleshchenko IG, Zabolotskiy DV, Yureva TN, et al. Anti-inflammatory effect of pterygopalatine blockade for anesthetization in ophthalmic surgery. Acta Biometrica Scientifica. 2018;3(1):82–88. EDN: YSMBYN doi: 10.29413/ABS.2018-3.1.12
  8. Oleshchenko IG, Yuryeva TN, Zabolotskii DV, Gorbachev NI. Blockade of the pterygopalatine ganglion as a component of combined anesthesia during surgery for congenital cataract. Regional Anesthesia and Acute Pain Management. 2017;11(3):202–207. (In Russ.) EDN: ZGVDAT doi: 10.18821/1993-6508-2017-11-202-207
  9. Shchuko AG, Iureva TN, Oleshchenko IG. Role of pterygopalatine blockade in the early rehabilitation program of children after congenital cataract surgery. Ophthalmology Reports. 2017;10(4):18–23. EDN: YMYPNY doi: 10.17816/OV10418-23
  10. Bahşi İ, Orhan M, Kervancıoğlu P, Yalçın ED. Morphometric evaluation and clinical implications of the greater palatine foramen, greater palatine canal and pterygopalatine fossa on CBCT images and review of literature. Surg Radiol Anat. 2019;41(5):551–567. doi: 10.1007/s00276-019-02179-x
  11. Carrier S, Castagneyrol B, Beylacq L, et al. Anatomical landmarks for maxillary nerve block in the pterygopalatine fossa: A radiological study. J Stomatol Oral Maxillofac Surg. 2017;118(2):90–94. doi: 10.1016/j.jormas.2016.12.008
  12. Marini K, Garefis K, Skliris JP, et al. Adenoid Cystic carcinoma of pterygopalatine fossa: report of a rare case. Indian J Otolaryngol Head Neck Surg. 2024;76(4):3493–3496. doi: 10.1007/s12070-024-04582-2
  13. Masabni O, Ahmad M. Infraorbital foramen and pterygopalatine fossa location in dry skulls: anatomical guidelines for local anesthesia. Anat Res Int. 2017;2017:1403120. doi: 10.1155/2017/1403120
  14. Puche-Torres M, Blasco-Serra A, Campos-Peláez A, Valverde-Navarro AA. Radiological anatomy assessment of the fissura pterygomaxillaris for a surgical approach to ganglion pterygopalatinum. J Anat. 2017;231(6):961–969. doi: 10.1111/joa.12690
  15. Digilli Ayaş B, Çiçekcibaşı AE, Gökşan AS, et al. Clinically relevant morphometric analysis of pterygopalatine fossa and its volumetric relationship with adjacent paranasal sinuses: a CT-based study. Oral Radiol. 2024;40(2):285–294. doi: 10.1007/s11282-023-00735-1
  16. Gibelli D, Cellina M, Gibelli S, et al. Anatomy of the pterygopalatine fossa: an innovative metrical assessment based on 3D segmentation on head CT-scan. Surg Radiol Anat. 2019;41(5):523–528. doi: 10.1007/s00276-018-2153-7
  17. Lentzen MP, Safi AF, Riekert M, et al. Volumetric analysis of the pterygopalatine fossa by semiautomatic segmentation of cone beam computed tomography. J Craniofac Surg. 2020;31(5):1334–1337. doi: 10.1097/SCS.0000000000006387
  18. Li J, Szabova A. Ultrasound-guided nerve blocks in the head and neck for chronic pain management: the anatomy, sonoanatomy, and procedure. Pain Physician. 2021;24(8):533–548.
  19. Polkovova IA, Aleshkina OYu, Nikolenko VN, et al. The typical variability of the pterygomaxillary fissure depending on shape of facial skull. Morphological Newsletter. 2017;25(2):57–59. EDN: YTYLVZ doi: 10.20340/mv-mn.17(25).02.11
  20. Tekin AM, Elsamanody AN, Ali IM, Topsakal V. Endoscopic endonasal removal of stray bullets in the fossa pterygopalatine in innocent young bystanders of conflicts in somalia in a period of six months. J Craniofac Surg. 2022;33(2):e130–e133. doi: 10.1097/SCS.0000000000008030
  21. Merkulov OA, Gorbunova TV, Buletov DA, Polyakov VG. Endoscopic endonasal approach for the tumor removal in children with the nasal cavity and paranasal sinuses cancer with skull base metastases. Onkopediatria. 2017;4(4):269–282. (In Russ.) EDN: ZXOYCV doi: 10.15690/onco.v4i4.1813
  22. Erdogan N, Erdogan U, Baykaraa M. CT anatomy of pterygopalatine fossa and its communications: A pictorial review. Comput Med Imaging Graph. 2003;27(6):481–487. doi: 10.1016/s0895-6111(03)00038-7
  23. Mikhailova RP. Age and individual variability of the wing fossa and its contents [dissertation abstract]. Kalinin; 1972.18 p. (In Russ.)
  24. Tsybul'kin AG. Surgical anatomy of the deep facial masses [dissertation abstract]. Moscow; 1971. 18 p. (In Russ.)

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. Pterygopalatine fossa of a child 3 years 4 months old. Fragments of computed tomography scans in the axial plane: a — at the level of 3 mm above the mouth of the large palatine canal; b — in the plane of the pterygoid canal; c — 1 mm higher; d — at the level of the round hole. 1 — maxillary sinus; 2 — front wall of pterygopalatine ganglion; 3 — orbital process of the palatine bone; 4 — medial wall of pterygopalatine ganglion; 5 — anterior edge of the pterygoid process; 6 — pterygomaxillary fissure; 7 — sphenopalatine foramen; 8 — sphenoid process of the palatine bone; 9 — vestibule of the pterygoid canal; 10 — pterygoid canal; 11 — central part of pterygopalatine ganglion; 12 — vestibule of the pterygomaxillary fissure; 13 — fragment of the pterygoid sinus; 14 — palatovaginal canal; 15 — orbit; 16 — posterior ethmoidal cells; 17 — wall of the sphenoid sinus; 18 — body of the sphenoid bone; 19 — round foramen; 20 — inferior orbital fissure.

Download (1MB)
Indexing metadata
3. Fig. 2. Pterygopalatine fossa of a child 4 years 2 months old. Fragments of CT scans in the frontal plane: a — at the level of the orifice of the greater palatine canal; b — 3 mm posteriorly from the plane of the orifice of the greater palatine canal; c — 2 mm posteriorly from the previous section; d — at the level of the anterior foramen of the pterygoid canal. 1 — central part of pterygopalatine fossa 2 — bottom of the sphenoid sinus; 3 — sphenopalatine foramen; 4 — medial wall of pterygopalatine fossa; 5 — nasal cavity; 6 — orifice of the greater palatine canal; 7 — maxillary sinus; 8 — vestibule of the greater palatine canal; 9 — vestibule of the pterygomaxillary fissure; 10 — lower orbital fissure; 11 — vestibule of the pterygoid canal; 12 — sphenoid sinus; 13 — pterygoid process; 14 — base of the pterygoid process; 15 — greater wing of the sphenoid bone; 16 — round foramen; 17 — medial plate of the pterygoid process; 18 — lateral plate of the pterygoid process; 19 — pterygoid canal; 20 — body of the sphenoid bone; 21 — throat; 22 — middle cranial fossa.

Download (1MB)
Indexing metadata
4. Fig. 3. Three-dimensional reconstruction of the pterygopalatine fossa of a child 3 years 8 months old: 1 — sphenopalatine foramen; 2 — round foramen; 3 — bottom of the sphenoid sinus; 4 — sphenoid process of the palatine bone; 5 — vestibule of the pterygoid canal; 6 — anterior opening of the pterygoid canal; 7 — pterygoid canal; 8 — central part of the pterygopalatine fossa; 9 — vestibule of the greater palatine canal; 10 — pterygomaxillary fissure; 11 — vestibule of the pterygomaxillary fissure.

Download (762KB)
Indexing metadata
